Hot Air Hopper Dryer for Plastic Industry with Custom Services
Uses of dehumidification dryer:
In addition to mainly targeting engineering plastics with strong hygroscopicity, it solves the problems caused by poor drying of products: bubbles, silver streaks, cracks, flow marks, poor transparency and other poor quality problems; engineering plastics such as: PA, PET, PU , TPU, PC, PBT, CA, etc. are highly hygroscopic. Since water penetrates into the interior of the plastic pellets, traditional dryers cannot completely dry them.
Principle of dehumidification dryer:
● Paired with a hot air hopper dryer to perform high-efficiency dehumidification and drying operations.
● Effectively lower the dew point of drying air to below -40℃ while controlling heat.
Only by blowing it over the surface of the moisture-containing plastic particles can the moisture content be reduced to less than 0.02% before molding.
● The honeycomb dehumidifier fully dehumidifies the air in a closed circulation system and quickly completely separates the moisture in the plastic particles to achieve the dehumidification and drying effect.
Three-in-one core technology
What occasion do you need me for?
Engineering plastics such as PA, PET, PU, TPU, PC, PBT, CA, etc. are highly hygroscopic. raw materials, because moisture penetrates into the plastic particles, the traditional hot air dryer is useless. Don't let it dry completely. The three-in-one dehumidification dryer is in a closed circulation system The air is fully dehumidified and heated, and the dry air quickly removes the moisture in the plastic pellets. Complete precipitation to achieve dehumidification and drying effect.
Dehumidification dryer---multiple models available
The honeycomb rotor with strong dehumidification performance is used to fully absorb the moisture in the air, and then a wind with a very low dew point and strong moisture absorption capacity is formed for dehumidification and drying of raw materials.
Honeycomb runner design, the dew point is stable below -40℃, ensuring the high quality and stability of molded plastic products. The whole series adopts standard equipment of P.I.D temperature control system; the control is equipped with LED liquid crystal display and automatic control.
Three-in-one dehumidifier
Dehumidification + drying + feeding three-in-one series; integrating the three functions of drying, dehumidification and feeding.
It is especially suitable for places with high degree of automation and compact space. The whole machine is controlled by PLC and is easy to operate.
An optional dew point meter that can monitor the dehumidification effect of the machine at any time is also available. Combined with the requirements of European design, the machine has a more beautiful appearance, more stable performance and lower energy consumption.
Technical parameters of dehumidification dryer (three machines in one)
| Model | GX-90L/80A | GX-120L/80A | GX-160L/80A | GX-230L/80A | GX-300L/80A | GX-450L/80A | |
| Drying hopper | Capacity | 90 | 120 | 160 | 230 | 300 | 450 |
| Insulation Materials | Fiberglass insulation + exterior panels | ||||||
| Average dry air dew point | -40℃ | ||||||
| Drying temperature | 80~160 | ||||||
| Drying air volume | 80 | 80 | 130 | 160 | 220 | 300 | |
| Drying fan | 0.75 | 0.75 | 1.1 | 1.5 | 2.2 | 3 | |
| Regeneration fan | 0.25 | 0.25 | 0.25 | 0.55 | 0.55 | 0.75 | |
| Dry electric heat | 3.9 | 6 | 6 | 7.2 | 12 | 15 | |
| Regenerative electric heat | 3.9 | 3.9 | 3.9 | 5.4 | 5.4 | 7.2 | |
| Pipe diameter | Dry | 51 | 51 | 51 | 63 | 63 | 76 |
| Cool down | 3/4″ | ||||||
| Regeneration | 38 | 38 | 38 | 51 | 51 | 63 | |
| Feeding fan | 1.1 | 1.1 | 1.1 | 1.5 | 1.5 | 1.5 | |
| Conveying distance | One feed | 10 | |||||
| Secondary feeding | 10 | ||||||
| Feeding piping | 1.5 | ||||||
| Electric eye hopper | 6 | 6 | 12 | 12 | 12 | 12 | |
| Vacuum hopper | 6 | 6 | 12 | 12 | 12 | 12 | |
| Dimensions | 180×100×87 | 180×100×87 | 180×100×87 | 225×165×125 | 225×165×125 | 290×150×130 | |
| Net weight | 310 | 340 | 360 | 420 | 550 | 600 | |
A corner of the dehumidification dryer workshop
Company Advantages
· The production environment of Gaoxin Machinery hot air hopper dryer meets the estimated standards.
· Owing to its stable ability, hot air hopper dryer have been highly favored by the majority of our customers.
· Dongguan Gaoxin Machinery Co., Ltd. will promote innovation work, and strive to develop more, newer and better products.
Company Features
· With years of commitment to hot air hopper dryer production, Dongguan Gaoxin Machinery Co., Ltd. has been acting flexibly to the market and gained recognition.
· We have established a wide range of solid customer base. Our customer base spans over decades throughout Africa, the Middle East, the USA, and parts of Asia.
· The team at Dongguan Gaoxin Machinery Co., Ltd. are all experts in their field and are ready to help you with any enquiry you have. Welcome to visit our factory!
Application of the Product
Gaoxin Machinery's hot air hopper dryer can be applied to different fields.
Through problem analysis and reasonable planning, we provide our customers with an effective one-stop solution to the actual situation and needs of customers.
