Gaoxin Machinery Plastic Dryer Manufacturing
Product details of the plastic dryer
Product Overview
Raised production technique: the production technique of Gaoxin Machinery plastic dryer is updated based on our rich production experience. It has evolved greatly over the past years. plastic dryer shows good comprehensive properties performance. Gaoxin Machinery's plastic dryer can play an important role in various fields. The product has gained the trust of the clients around the world and will be more applied in the coming future.
Product Information
The details of plastic dryer are shown for you at below.
Box dryer uses:
● Widely suitable for drying any plastic materials, and can dry materials of different materials and colors at the same time.
● Especially suitable for drying materials that require high temperature accuracy, low dosage, and various colors.
It is also suitable for use in preheating or drying processes in food, pharmaceutical, electronic plating and other industries.
Working principle of box dryer;
● Put the materials to be dried into the movable material tray. When the power is turned on, the powerful wind wheel will turn on;
● Start up and force the air entering from the air inlet to blow towards the electric heating tube. The air will be heated by the electric heating tube, pass through the perforated partition wall, and blow evenly towards the materials. The air carrying moisture will be drawn out of the oven by the dehumidification fan at the top. outside.
Repeating this cycle will achieve the effect of moisture removal and drying.
Applicable industries - widely used
Box dryer, industrial drying oven
Can dry materials of different materials and colors at the same time
Preheating or drying treatment for various plastics, food, pharmaceuticals, electronic plating and other industries
Multiple models available
5-40 layers can be ordered, adjustable within 250℃
Box dryer structure diagram
Technical parameters of box dryer
| Model | Power | Capacity（KG） | Dimensions（L*W*H/（MM）） | Internal Dimensions | Weight | Temperature control range | |
| Motor | Electro-thermal | （L*W*H/（MM）） | (KG) | (℃) | |||
| Model | Motor | Electrothermal | Capacity | Qutlie dimesions | Iteral dimesios | The weight of the body | Tempetature range |
| XG-5th floor | 0.37 KW | 4.5KW | 45KG | 810*760*1250 | 600*560*600 | 115 | 250℃ |
| XG-9th floor | 0.37 KW | 6KW | 90KG | 810*760*1500 | 600*560*900 | 150 | 250℃ |
| GX-20th floor | 0.75 KW | 12 KW | 180 KG | 1350*780*1800 | 1100*620*1100 | 300 | 200℃ |
Workshop corner
Company Information
Dongguan Gaoxin Machinery Co., Ltd. is an integrated company in dong guan. Our company is mainly engaged in the production, processing and sales of Plastic machinery and general machinery,Plastic Crusher,Mixer Dryer Machine,Plastic Recycling Machine,Industrial Chiller. Gaoxin Machinery receives trust and favor from new and old customers based on high-quality products, reasonable price, and professional services. The products we produced are excellent in quality and cost-effective. If in need, please contact us!
